Máy Tuốt và Xoắn Dây Điện Tử Khí Nén Chính Xác WPM-200T

Detailed description

Máy tuốt và xoắn dây khí nén WPM-200T - Tăng hiệu quả và giảm cường độ lao động

Giới thiệu:

Giới thiệu Máy tuốt và xoắn dây WPM-200T, một giải pháp chạy bằng khí nén được thiết kế để nâng cao đáng kể quy trình xử lý dây của bạn. Máy hiệu quả này, Máy xoắn tuốt dây khí nén, được thiết kế chuyên nghiệp cho cả các ứng dụng xoắn tuốt dây và tuốt dây và máy xoắn. Là một máy xoắn tuốt dây đa lõi bằng tay khí nén, WPM-200T vượt trội trong việc xử lý nhiều loại dây khác nhau, đặc biệt là dây nhiều lõi, với tốc độ và dễ dàng đáng kể. Trải nghiệm hiệu suất máy tuốt dây và xoắn chất lượng cao giúp giảm mệt mỏi cho công nhân, đơn giản hóa hoạt động và cải thiện đáng kể hiệu quả sản xuất của bạn.

Key Features for Enhanced Efficiency and Ease of Use:

The WPM-200T Wire Stripping And Twisting Machine is equipped with a range of features designed for superior performance and operator convenience:

• Electric Footswitch Control for Reduced Labor: Utilizes electric footswitch control, significantly reducing worker labor intensity. This hands-free operation allows operators to focus on wire handling, minimizing fatigue and improving overall ergonomics.
• Convenient and Simple Operation: Designed for user-friendliness, the machine is incredibly convenient and simple to operate. Ordinary employees can be easily trained to effectively use and maintain the machine, minimizing training costs and maximizing workforce adaptability.
• Clip Wire Module System for Secure Gripping: Features a clip wire module system. As wires are clipped into these modules, they are securely gripped, ensuring stable and precise processing throughout the stripping and twisting cycle.
• Automated Template-Based Processing: Employs an automated work template system. Once wires are clipped, initiating the footswitch starts the template, linking piece slides to move up and down and positioning the wires accurately within the template for consistent processing.
• Cylinder-Driven Blade for Precise Stripping: The blade is driven by a cylinder bridge, ensuring powerful and precise stripping action. This pneumatic drive guarantees clean and consistent stripping results every time.
• Rack and Pinion Gear Driven Twisting Mechanism: Utilizes a sophisticated rack and pinion gear system driven by a cylinder. This robust mechanism, coupled with large gears, ensures wires are twisted together efficiently and securely, creating reliable connections.
• Two-Step Process for Optimized Results: The machine divides the wire stripping and twisting process into two distinct steps. This separation ensures each stage is completed optimally, resulting in high-quality stripping and twisting outcomes and minimizing processing errors.

Suitable for a Variety of Wire Types:

This Pneumatic Wire Stripping Twisting Machine is versatile enough to handle a range of wire types commonly used in various industries:

• Power Lines
• Electronic Wires
• Multicore Wires
• And similar wire types requiring stripping and twisting

Technical Specifications for Efficient Pneumatic Operation:

• Name: Stripping and Twisting Machine
• Model: WPM-200T
• Key Functions: Wire Stripping And Twisting Machine, wire stripping twisting, wire stripping, and twisting machine, Pneumatic Wire Stripping Twisting Machine, Pneumatic Manual Multi-Core Wire Stripping Twisting Machine, High-Quality Wire Stripping, And Twisting Machine
• Air Source Requirement: 6KG (Standard pneumatic pressure)
• Strip and Twist Length: 3-45MM (Adjustable stripping and twisting length)
• Power Supply: 220V (50HZ) (Standard Voltage)
• Power Consumption: 30W (Energy Efficient)
• Suitable Wire Types: Power Line, Electronic Wire, Multicore Wire (Versatile material compatibility)
• Length Requirement: 〉5mm (Minimum wire length requirement)
• Weight: 12KG (Portable and Lightweight)
• Machine Size: 320mm * 180mm * 170mm (Compact Benchtop Design)

Kết thúc:

Invest in the WPM-200T Pneumatic Wire Stripping Twisting Machine to transform your wire processing and significantly reduce worker strain. This efficient and user-friendly machine, a leading High-Quality Wire Stripping, And Twisting Machine, delivers unmatched pneumatic power and precision, making it the ideal Wire Stripping And Twisting Machine for maximizing your production output and product quality. Contact us today to learn more about how the WPM-200T can revolutionize your wire harnessing and elevate your manufacturing capabilities!
